Description
-
DC9～57V PoE SWITCH: Support DC9～57V input and IEEE802.3af/at PoE output with built-in voltage booster. (Noted: Supports Mode A PoE output, if your PoE Device is Mode B, pls buy another PoE Switch: POE-Switch0504GD).
-
FULL GIGABIT: Providing 4x 10/100/1000Base-T Ethernet PoE ports and 1x 1000Base-X SFP slot (SFP module not included). All PoE ports are compliant to IEEE802.3af/at. Total PoE budget 120W (DC24V/DC48V input) or 60W (DC12V input).
-
INDUSTRIAL DESIGN: Compact IP40 rugged metal enclosure; Wide working temperature -40 ℉ to 185 ℉ (-40°C to 85°C); Support DIN-Rail & Wall Mount.
-
REDUNDANT POWER SUPPLY: Support 2 channel DC9～57V redundant power inputs and auto failover, ensure high reliability networking system.
-
STANDARD PoE - Unlike some software emulated PoE, this PoE Switch adopts hardware IEEE802.3af/at PoE chipset and compatible to Mode A PD device. It follows PD Detection -> Classisication Type -> Power On procedures to prevent stanard PD device from damaging.
-
APPLICATIONS: Standard PoE supply in solar power system (DC12V/DC18V/DC36V input), RV/Vehicle/Truck/Bus (DC12V input), VoIP/Access control systems (DC24V input).
Interface
Outstanding Features
Application1 - DC12V Solar Power Systems
Application2 - Vehicle POE Supply
Application3 - DC24V Input
Harsh Environment
Package & Installtion
Key Spesifications
