Description
- BT 90W POE EXTENDER - Boost and split BT90W PoE to two PoE outputs (1x60W + 1x30W).
- GIGABIT ETHERNET REPEATER - Extend extra 100 meters POE+Ethernet network at Gigabit 1000Mbps bandwidth.
- OUTDOOR RATED - Aluminum housing, IP67 waterproof standard, 4KV lightning protection, designed for harsh environments.
- POE SPLITTER - Run one network cable to provide PoE power + network for two PoE or non-PoE devices.
- INTELLIGENT LED INDICATOR - For easy checking of the connection status of the device.
- Plug-n-Play - No configuration is required.
Application
- Offer max 60W POE for PTZ Camera, IP Speaker, VoIP phones, Wireless AP, etc.
- POE passthrough switch, poe splitter, run one network cable to provide PoE power + network for two PoE or non-PoE devices.
- Extend extra 100 meters to connect POE devices or network devices.
- Bundled with a variety of PoE splitters to provide Ethernet data, DC12V, DC24V, PoE 24V, USB-C outputs
Frequently bought with
The bundle
This Item
x1
+
This item
Frequently bought with
Related Item to Consider
LINOVISION 2 Ports 90W Gigabit Waterproof PoE Extender
POE passthrough switch, POE splitter, run one network cable to provide PoE power & network for two PoE or non-PoE devices, suitable for IP camera, PTZ camera, POE speaker, Wireless AP, etc.
Application
Package & Installation
Key Specification
| Model | POE-EXT6002GP |
|---|---|
| Standard | IEEE802.3, IEEE802.3u, IEEE802.3ab,, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.3bt |
| Port |
PoE in port: 1 x 10/100/1000Mbps RJ45 port PoE out port : 2 x 10/100/1000Mbps RJ45 port |
| Network Media(Cable) |
10BASE-T: UTP category 3,4, 5 cable (≤100m) 100BASE-TX: UTP category 5,5e cable (≤100m) 1000BASE-TX: UTP category5e cable (≤100m) |
| LED | LAN |
| PoE Standard | IEEE802.3af/at/bt |
| Dimensions (L*W*H) | 150*73*44MM |
| RJ45 PoE | Anode3/6 Cathode1/2 and Anode4/5 Cathode7/8 |
| PoE port | 2 |
| Power Supply | PoE |
| PD port input | 90W |
| PoE Power Output | Per port 48-55V DC Port 1: 30W Max Port 2: 60W Max |
| Operating Temperature | -20°C ~ 60 °C |
| Storage Temperature | -40 °C ~ 80 °C |
| Operating Humidity | 10% ~ 90% non-condensing |
| Storage Humidity | 5% ~ 90% non-condensing |
| Surge Protection | Differential mode±4KV, Common mode±6KV |
| MTBF | >50000 hour |
| Electrostatic standard | Contact 6KV,air 8KV |
| Weather Rating | IP67 |
| Vandal Proof | IK10 |
Comparison
LINOVISION PoE Extender Selection Guide
Learn more >
|
Learn more >
|
|
Learn more >
|
Learn more >
|
Learn more >
|
|
|---|---|---|---|---|---|---|
| Model | POE-EXT3001GP | POE-EXT3001LP (2 Pack) |
POE-EXT6002GP | POE-Extender02 | POE-EXT04 | POE-EXT9004G |
| PoE Input | Max 30W | Max 30W | Max 90W | Max 30W | Max 60W | Max 90W |
| PoE Output | 1 x 30W | 1 x 30W | 1 x 60W + 1 x 30W | 1 x 16W + 1 x 8W | 4 x 30W | 4 x 90W |
| PoE Standard | IEEE802.3af/at | IEEE802.3af/at | IEEE802.3af/at/bt | IEEE802.3af/at | IEEE802.3af/at | IEEE802.3af/at/bt |
| PoE Budget | 30W | 30W | 90W | 30W | 56W | 75W |
| Extend Extra Transmission Distance | Max.300m (3 pack) |
Max.900m (2 pack) |
Max.100m (1 pack) |
Max.200m (2 pack) |
Max.100m (1 pack) |
Max.250m (1 pack) |
| Ethernet Speed | Gigabit | 10/100Mbps | Gigabit | 10/100Mbps | Gigabit | 10/100/1000Mbps |
| Waterproof | ✔ | ✔ | ✔ | / | / | / |
| Installation Method | / | / | Wall-Mount | DIN-Rail/Wall-Mount | / | DIN-Rail/Wall-Mount |
